Product Details
＋
TRA-22D-B-230, 22mm LED Ammeter BLUE 0-100Amp 240VAC, Plastic, IP40, IEC60947-5-1
LED indicator Series will activate while the contacts are connected to the rated voltage. Widely Used for Rugged Industrial Applications Including Critical Machinery requiring safe operation and visual Indication by the user.
Features :
- 240VAC Supply
- 0-100Amp Measurement
- LED Illumination
-
Ø 22.5mm Cutout
- Long Life
- LED Replacement Beads Available
- RED, GREEN, AMBER, BLUE, or Clear\White Colour
Standards :
- IP40
- IEC60947-5-1
- CE
Specification
| TRENT Part Number | TRA-22D-B-230 |
| Functions | LED Ammeter |
| Measurement Range | 0-100Amp AC |
| Nominal Voltage | 230VAC @ 50/60Hz |
| Impulse Voltage Wear Resistance | 6kV |
| Illumination Type | Blue LED |
| Short Circuit Protection (Fuse) | Recommend 10A gG Fuse |
| Mechanical Compression Force at Closing | 20N |
| Mechanical Compression Force at Closing | 8N |
| Humidity | 35-85% |
| Approvals | CE |
| Standards | IP65, IEC60947-5-1 |
| Weight | |
| Enclosure Material | UL94V0 |
| Factory Pack Qty | 1 |
| TRENT(Fastron) Head Office | Australia |
