| Product Attribute | Attribute Value |
|---|---|
| Connection | 1/8 NPT, M5 Female Thread |
| Display | 4-Digit, 7 Segment, 2-Color LCD (red/green) |
| Function | High Precision, Digital Positive Pressure Sensor |
| IP Rating | IP40 |
| Measurement Range | –0.100 to 1.000 MPa |
| Mounting Type | Panel Mount/Bracket |
| Output | NPN Open Collector 1 Output, Analog Voltage Output |
| Output Type | NPN |
| Power Supply | 12 to 24 VDC |
| Pressure, Operating | -14.5 to 145.04 PSI (-0.1 to 1 MPa) |
| Primary Type | Pressure |
| Sensing Mode | Air, Non-Corrosive Gas, Non-Flammable Gas |
| Series | |
| Set Point | -0.105 to 1.05 MPa |
| Size, Port | 1/4" NPT |
| Supply Voltage | 12 to 24 VDC |
| Termination | Leadwires |
Overview
SMC's ISE30A (pressure) and ZSE30A (vacuum) digital pressure sensors follow in the tradition of the ISE30 and ZSE30 pressure sensors. Now with added features including dual color display, the 30A series comes with the unique copy feature where the stored parameters in one switch can be copied to up to 10 additional sensors simultaneously, removing the need to manually upload settings and parameters. These high precision, compact sensors are optimal for both machine and panel mounting. The 2-color display transitions from red to green based on process changes. These changes can be monitored as either digital and/or analog outputs. Clear pressure monitoring eliminates guessing and reduces or eliminates time spent retuning or recalibrating equipment.
Features:
One-Touch Fitting Economical Use of Space Raised Rubber Button Controls, Simple to Operate Plug-In Type Connectors High-Precision Resolution 1/1000
