Equipped with a total of forty 15 W RGBW LEDs for a massive 21,000 lm output, the Cameo ZENIT® W600 is a powerful IP65 rated wash light for demanding outdoor applications. In addition to RDM and standard DMX capability it boasts a built-in 2.4 GHz W-DMX™ transceiver by Wireless Solution Sweden AB for convenient wireless control. The fixture also provides a rich variety of stunning automated programs for standalone or wireless master-and-slave operation.
For maximum versatility, the ZENIT® W600 sports Cameo’s innovative SnapMag® technology. It allows you to add filter frames in less than a second without the need for tools or dismantling. Magnetic SnapMag® frames with precision light shaping diffusers providing a choice of 25°, 45°, 100° or elliptical 60° x 10° beam angles and a 4-way barn door are available as dedicated accessories.
Specifications
- Product type: LED Outdoor Wash Light
- Type: ZENIT
- Colour spectrum: RGBW
- Number of LEDs: 40
- LED Type: 15W
- Average LED lifetime: 50000 hrs
- Refresh rate: Adjustable: 800Hz, 1200Hz, 2000Hz, 3600Hz, 12000Hz, 25000 Hz
- Dispersion: 18° Beam, 35° Field (without diffusor) °
- Lens: PE and tempered glass
- DMX Input: 5-pin IP65
- DMX Output: 5-pin IP65
- DMX Mode: 10-channel, 15-channel, 2-channel, 3-channel, 4-channel, 8-1 Channel, 8-2 Channel
- DMX Function: Auto programs, colour macro, CTC (Colour Temperature Correction), Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, RGBW, RGBW Fine, strobe
- Standalone Modes: Auto programs, colour macro, Master / Slave mode, Settings, Static, system info, Tunable White, User Colours
- Controls: Enter, Mode, Value Down, Value Up
- Indicators: OLED Display
- Operating voltage: 100 V AC – 240 V AC, 50 – 60 Hz
- Power consumption: 565 W
- Power Factor: 0,99 FP (120 V) / 0,96 FP (230 V)
- Power connector: IP65
- Power supply connection: IP65
- Housing material: Aluminium
- Cabinet colour: Black
- Protection class IP: IP65
- Cooling: IP65 temperature-controlled fans
- Luminous flux: 21000 lm
- Efficiency: 37,2 lm/W
- Operating Temperature: -15 – 45 °C
- Accessories (included): 2 x omega mounting
- Other features: ETL certified
Dimensions
- Width: 463 mm
- Length: 291 mm
- Height: 161 mm
- Weight: 13 kg
