Item# 8689

Features:

• Isolates the Engine circuit from the House circuit
• Protects electronics from sags and spikes caused by engine cranking

Specifications:

• Positions:7
• Nominal Voltage:
• 12V DC
• 24V DC
• Maximum Voltage:32V DC
• Continuous Rating:300A
• Intermittent Rating: 450A (5 min)
• Cranking Rating 10 sec:1000A
• Cranking Rating 1 min: 650A
• Height:7.25in (184.15 mm)
• Width: 7.25in (184.15 mm)
• Depth:3.25in (82.55 mm)
• Weight:3.46lb (1.57 kg)
