Product Details
＋
The MA500-HS provides an economical solution for digital imaging with your microscope. You can view a live stream on your PC, and snap 5-megapixel photos and capture high-resolution videos.
The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. With the ability to calibrate scales at multiple magnifications, the software can be used for multi-level inspection. Independent preview and capture resolutions allow you to view high-speed video while simultaneously capturing high-definition images.
Sensor
| Sensor | Sensor Type | Sensor Format | Pixels |
|---|---|---|---|
| Sony | CMOS | 1/2.8" | 5M (2560x1920) |
| Pixel Size | Shutter | Sensitivity ?
|
Saturation Signal |
| 2.0µm x 2.0µm | Rolling Shutter | 500mV @ 1/30s (f5.6) | 880mV |
Camera
| Frame Rate(s) | Connectivity | Lens-mount |
|---|---|---|
| 22fps@2560x1920 | USB 2.0 | C-mount |
| Compensating Lens | Exposure Time | Compatibility |
| 0.37X (not included) | Windows (64 bit) 7/8/10 |
Software
| OS Requirements | Windows (64 bit) 7/8/10 | |||||||
|---|---|---|---|---|---|---|---|---|
| Hardware Requirements | Intel Core i5 or better(Quad or more Core), 8GB RAM, USB3.0 port for maximum speed | |||||||
| Features |
|
